High Temperature Mechanical Melt Presssure Gauges
PG112/PG123/PG133 mechanical high-temperature melt pressure gauge for plastic extrusion, for plastic injection molding is a crucial component in the plastic extrusion process, allowing operators to monitor and control the pressure of the molten plastic as it passes through the extruder.
The design on the rigid snout version of the mechanical gauge can be rotated for unobstructed viewing, and the optional built-in pressure transducer with 2.0mV/V output and pressure transmitter with 4~20mA output is available to monitor in remote by working with pressure indicators. Thermocouple or RTD configurations are available to provide melt temperature.
Description
Features
Pressure range:0～100bar or 0～1000bar;
Accuracy level:±1.6%F.S;
Special diaphragm coating;
IP65 protection level;
4～20mA signal output available.
Application Area
Chemical Fiber Industry;
Injection Molding Industry;
Rubber&Plastics Industry
Product Description
High temperature melt pressure gauge series is designed to measure pressure at high temperature in the industries of injection molding and chemical fiber, special diaphragm and highly anti-abrasive coating of which enable it to work normally at high temperature of 400℃.It adopts standard threaded connection and is characterized by high stability and long service life.
Technical Parameters
|
Sigal Output |
4~20mA available |
|
Accuracy |
±1.6%F.S |
|
Pressure Range |
0~100bar,0~1000bar |
|
Pressure Unit |
psi,bar |
|
Overload Capacity |
1.5 times rated pressure |
|
Zero Temperature Drift |
0.005MPa/℃ |
|
Electrical Environment Temp |
-20℃~85℃ |
|
Diaphragm Material |
15-5PH |
|
Diaphragm Temp |
400℃ |
|
E-connection |
5-pin standard aviation connector |
|
Mounting Torque |
40N.m,max |
|
Process Connection |
1/2-20UNF |
|
Protection Level |
IP65 |
|
Temp Measuring Components |
E,J,Ktype or Pt100 |
External dimension
|
D1 |
D2 |
D3 |
D4 |
D5 |
A |
B |
C |
|
1/2UMF |
φ7.8 |
φ10.5 |
φ10.5 |
φ12.7 |
5.5 |
11.5 |
16 |
|
M14×1.5 |
φ7.8 |
φ11.5 |
φ11.7 |
φ12.7 |
5.5 |
11.5 |
16 |
|
M18×1.5 |
φ9.8 |
φ15.8 |
φ12.7 |
φ12.7 |
5.5 |
14.5 |
20 |
ordering guide
|
Serie No |
PG |
X |
- |
X |
- |
X |
- |
X |
X |
- |
X |
- |
X |
- |
X |
|
|
Product type |
rigid stem |
112 |
||||||||||||||
|
flexible |
123 |
|||||||||||||||
|
dual measurement |
133 |
|||||||||||||||
|
Pressure range |
10MPa 100bar 1500psi |
1.5M |
||||||||||||||
|
20MPa 200bar 3000psi |
3M |
|||||||||||||||
|
25MPa 250bar 3500psi |
3.5M |
|||||||||||||||
|
35MPa 350bar 5000psi |
5M |
|||||||||||||||
|
40MPa 400bar 6000psi |
6M |
|||||||||||||||
|
50MPa 500bar 7500psi |
7.5M |
|||||||||||||||
|
70MPa 700bar 10000psi |
10M |
|||||||||||||||
|
100MPa 1000bar 15000psi |
15M |
|||||||||||||||
|
Process connection |
1/2-20UNF |
1/2 |
||||||||||||||
|
M14×1.5 |
M14 |
|||||||||||||||
|
M18×1.5 |
M18 |
|||||||||||||||
|
M22×1.5 |
M22 |
|||||||||||||||
|
G3/8 |
G3/8 |
|||||||||||||||
|
Rigid stem |
6 inches(152mm) |
6 |
||||||||||||||
|
9 inches(229mm) |
9 |
|||||||||||||||
|
12.5 inches(318mm) |
12 |
|||||||||||||||
|
15 inches(381mm) |
15 |
|||||||||||||||
|
18 inches(460mm) |
18 |
|||||||||||||||
|
Flexible |
18 inches(460mm) |
/18 |
||||||||||||||
|
24 inches(610mm) |
/24 |
|||||||||||||||
|
30 inches(760mm) |
/30 |
|||||||||||||||
|
Signal output |
None |
blank |
||||||||||||||
|
2mV/V |
2MV |
|||||||||||||||
|
4~20mA |
MA |
|||||||||||||||
|
0~10VDC |
10V |
|||||||||||||||
|
0~5VDC |
5V |
|||||||||||||||
|
Temperature component |
J type |
J |
||||||||||||||
|
K type |
K |
|||||||||||||||
|
E type |
E |
|||||||||||||||
|
three Pt100 RTD |
RTD1 |
|||||||||||||||
|
E-Connection |
None |
blank |
||||||||||||||
|
5-PIN standard aviation connector |
5P |
|||||||||||||||
