Radar Level Sensors
Industrial 80G Radar Level Sensor For Continuous Level Measurement Of Liquids And Bulk Solid, Low MOQ and Custom available
Description
Features of Ziasiot 80Ghz Radar Level Sensor?
The Ziasiot RD80G series radar level sensor is for continuous level measurement Of liquid/tank/silo/bin/cement/grain warehouse/Slurry, etc., measuring range from 0 to 100 m.
The features are
- 1 mm high accuracy
- 3° beam angle
- 80GHZ FM Continuous Wave
- Protection level is IP68, pressure resistance can reach 0.1-0.5MPa, temperature resistance can reach 100 degrees
- The measuring range can reach 120 meters, and the shell can be made of stainless steel & cast aluminum
- Customization Support: OEM and ODM support
- Multiple connection methods, flange, bracket, thread, clamp connection
- Robust construction with materials such as PTFE, aluminum, and stainless steel, providing excellent durability and resistance to harsh environments (IP67 rating).
- Customizable output signal, RS485 & 4-20mA can be selected, and Customizable Bluetooth function
Description of Ziasiot 80Ghz Radar Level Sensor
The RD80G series radar level sensor refers to frequency-modulated continuous wave (FMCW) radar products that operate at 76-81GHz, supporting four-wire and two-wire applications. In multiple models, the maximum range of the product can reach 120m, and the blind spot can reach 8 cm. Due to its higher operating frequency and shorter wavelength, it is particularly suitable for solid-state applications. The working method of transmitting and receiving electromagnetic waves through a lens has unique advantages in high-dust and harsh temperature environments (+200 ℃). The instrument provides a flange or threaded fixing method, making installation convenient and simple.
Product Parameters
Measuring medium: Liquid is without corrosion
Measuring range: 0.05m-10/20/30/60/100m
Process connection: Thread G¾"A / ¾"NPT; Flange ≥DN40
Process temperature: -40～80℃
Process pressure: -0.1～0.3 MPa
Antenna size: 32mm lens antenna
Antenna material: PTFE
Accuracy: ±1mm Protection level: IP67
Center frequency: 123GHz Launch angle: 3°
Shell: Aluminum/Plastic/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Measuring medium: no-corrosive liquid, slightly corrosive liquid
Measuring range: 0.05m-10/20/30/60/100m
Process connection: Flange DN80
Process temperature: -40～110℃
Process pressure: -0.1～1.6 MPa
Antenna size: 32mm lens antenna
Antenna material: PTFE
Accuracy: ±1mm(range below 35m)& ±5mmrange from 35m- 100m)
Protection level: IP67
Center frequency: 80GHz Launch angle: 3°
Shell: Aluminum/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Measuring medium: strongly corrosive liquid, steam, foam
Measuring range: 0.05m-10/20/30/60/100m
Process connection: Flange DN50
Process temperature: -40～130℃
Process pressure: -0.1～2.5 MPa
Antenna size: 34mm lens antenna
Antenna material: PTFE
Accuracy: ±1mm(range below 35m)& ±5mmrange from 35m- 100m)
Protection level: IP67
Center frequency: 80GHz Launch angle: 3°
Shell: Aluminum/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Measuring medium: strongly corrosive liquid, steam, foam
Measuring range: 0.1m-10/20/30/60/100m
Process connection: Flange DN50
Process temperature: -40～130℃
Process pressure: -0.1～1.0 MPa
Antenna size: 76mm lens antenna
Antenna material: PTFE
Accuracy: ±1mm(range below 35m)& ±5mmrange from 35m- 100m)
Protection level: IP67
Center frequency: 80GHz Launch angle: 3°
Shell: Aluminum/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Measuring medium: strong corrosive liquid, steam, foam, high
temperature and high pressure
Measuring range: 0.1m-10/20/30/60/100m
Process connection: Flange DN80
Process temperature: -40～200℃
Process pressure: -0.1～2.5 MPa
Antenna size: 76mm lens/ integral fill antenna
Antenna material: PTFE
Accuracy: ±1mm Protection level: IP67
Center frequency: 80GHz Launch angle: 3°
Shell: Aluminum/Plastic/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Measuring medium: solids, storage containers, process containers, or strong dust situation
Measuring range: 0.3m-10/20/30/60/100m
Process connection: Flange DN100
Process temperature: -40～110℃
Process pressure: -0.1～0.3 MPa
Antenna size: 76mm lens antenna/ universal purge (or without a purge)
Antenna material: PTFE
Accuracy: ±5mm Protection level: IP67
Center frequency: 80GHz Launch angle: 3°
Shell: Aluminum/Plastic/Stainless steel
Signal output: Two-wire system/4…20mA/HART protocol
Four-wire system/4…20mA/HART protocol
Six-wire system/4…20mA/HART Protocol/RS485/Modbus protocol
Product Dimension
Applications
Packaging
Single package size: around 50X30X20 cm
Single gross weight: around 5.000 kg
