Hvac Pressure Transducer

PT230BN Differential Pressure Sensor Hvac is assembled by silicon piezoresistive differential pressure core, widely used for air or neutral gas detection, and the two pressure interfaces are 6 air pipe joints, it can be directly installed on the measuring pipeline or connected through the pressure pipe

Send Inquiry

Description

Features:

1. Imported sensor chips which are suitable for measuring in different pressure occasions.
2. Laser resistance adjustment compensates zero point and temperature performance
3. With short circuit protection and reverse polarity protection
4. Adopt high-precision AD and high-speed processor, full digital design.
5. High precision, high stability, high reliability, strong anti-interference ability.
6. Optional output current, voltage, RS485 and other signals.

Description:

PT230BN Hvac Pressure Transducer is assembled with OEM silicon piezoresistive differential pressure core. The two pressure interfaces are pagoda cock structures (users can choose the pressure interface size), which can be directly installed on the measuring pipeline or connected through the pressure pipe. There are voltage, current, 485 signal outputs to choose from, which are easy to install and use, and are widely used in pressure process control fields in the power and coal industries such as boiler air supply and underground ventilation.

Application:

1- Oil water differential pressure measurement, pressure detection inside pipes and vessels

2- HVAC Equipment, can be used for heating, refrigeration, and other air conditioning equipment

3- Gas alarm, gas leakage alarm device applied in lab

4- Integrated system, applied to detecting gas-integrated systems in various industries.

Specification

Type	Value	Type	Value
Pressure range	0～1Kpa~600Kpa	measurement accuracy	±0.25%,±0.5%
Stability	≤0.2% /年	Load resistance	≤(U-12)/0.02Ω
Pressure Type	Differential Pressure	Power supply	12~30VDC (suggetion: 24VDC)
Overload capacity	300%FS	Protection degree	IP54
Output	4～20mADC, 1～5V,0～5V,0～10V(three wire) ;RS485(four wire) ;
Temperature effect	Within the specified operating temperature range, the output change is ≤ ±0.05% of the range for every 10°C change in ambient temperature.
Medium temperature	-30℃~85℃	Operating temperature	-20℃~+70℃
Relative humidity	0~90%不冷凝	Storage temperature	-40℃~+90℃
