4-20mA Sanitary Temperature Transmitter

Pt100 4-20mA Sanitary temperature transmitter with Thermocouple sensor K,E,J,T,PT100,CU50 Adopt imported temperature sensing element
high precision, good stability
The structure is simple, easy to install
armored structure is easy to replace
Good seismic performance
Large measuring range, high mechanical
strength, good pressure resistance

Send Inquiry

Download

Description

Features

Adopt imported temperature sensing element, high precision, good stability The structure is simple, easy to install, armored structure is easy to replace Good seismic performance Large measuring range, high mechanical strength, good pressure resistance

Application

Products are widely used, mainly used in chemical industry, steel, metallurgy, pharmaceutical, food, new energy and so on.

Temperature range	-50 to +300°C
Model Name	ZTS 4-20mA PT100 temperature transmitter
measurement accuracy	0.2%FS, 0.3%FS, 0.5%FS
behaviour of electricity	Two wire system	Three-wire system 0 ~ 10v	three-wire system	three-wire system
output signal	(4～20)mA	(0～10)V	(0～5)V	(0.5～4.5)V
Power supply	6.5～32Vdc	12～32Vdc	10～32Vdc	5Vdc
Load resistance	＜(U-6.5)/0.02	＞20k	＞20k	＞20k
electrical connection	M12 connector, hessman, PACK connector, waterproof connector
Overload pressure	1.5 times rated pressure
Liquid Connection Material	SUS316L
The protection grades	IP67
Core Grade	CLASS A , CLASS1/3B
Long term stability	0.2%FS/year
