Intelligent Water Air Pneumatic Hydraulic Pump Digital Pressure Switch

Measuring Range: -0.1~0-0.02~100MPa
Measurement Accuracy: Class0.5,class0.25
Stability: ≤0.2% /year
Power supply: 15~36V.DC
Output form: 2 switch quantity（PNP/NPN)+4～20mA

Send Inquiry

Download

Description

Description:

Features:
Measuring Range -0.1~0-0.02~100MPa
Compact stainless steel housing package
Protection level IP65
Multiple electrical connection options

Description:
The ZSP202 intelligent pressure switch is an intelligent digital display pressure measurement and control product integrating pressure measurement, display, and output control. The product is a fully electronic structure, which measures and controls the pressure of the control system. The intelligent pressure switch is flexible to use, simple to operate, easy to debug, safe and reliable. Widely used in hydropower, tap water, petroleum, chemical, machinery, hydraulic and other industries to measure, display and control the pressure of fluid media

Application:
Hydraulic and pneumatic control
construction machinery
Light industry, machinery and metallurgy
Industrial process and control

product-1501-2142

PRODUCT PARAMENTERS

Measuring Range	-0.1~0-0.02~100MPa
Measurement Accuracy	Class0.5,class0.25
Stability	≤0.2% /year
Display Method	4-digit digital tube unit display
Type of pressure	Gauge pressure, absolute pressure, sealed gauge pressure
Display range	-1999~9999
Overload capacity	1.5times full scale
Maximum power consumption	≤1W
Power supply	15~36V.DC
The protection grades	IP65
Switch load capacity	＜1.2A(24V.DC)
Output form	2 switch quantity(PNP/NPN)+4～20mA
Load resistance	≤(U-12)/0.02Ω
Switch life	＞10years
Response time	≤5ms
Medium temperature	-40℃~85℃
Ambient temperature	-40℃~70℃
Relative temperature	0~95%
Storage temperature	-20℃~60℃
Temperature effect	Within the specific working temperature,the output change≤±0.05％ of the range for every 10℃ change in the ambient temperature
