Digital Melt Presssure Gauges

Φ100mm standard gauge installation
special diaphragm coating
4 digit LED display,no indication error
two way relay control output 220 3A
4-20mA signal output,on-site control point setting
accuracy:0.5% FS

Chemical Fiber Industry;
Injection Molding Industry;
Rubber&Plastics Industry

This series of products is designed for pressure measurement in high temperature environment.It aopts on-site LED display without indication error,two way relay output,stable work performance at 400 It uses standard thread connection and is characterized by high stability and long service life.

Pressure Range: 0～3.5MPa OR 0～200MPa
Combined Accuracy: ±0.5%
Diaphragm Material: 17-4 PH with anti-abrasive coating,other coating available
Overload Capacity: 1.5 times rated pressure
Display Method: 0.56" Nixie Tube
Indication Range: -1999～9999
Signal Output: 4-20mA with two way relay output
Power Supply: 24VDC/220VAC
Process Connection: 1/2-20UNF,M14×1.5,M18×1.5,M22×1.5
Response Time: ﹤30mS
Diaphragm Temp: 400℃
Electrical Temp.: -20℃～70℃
Temp. Drift: IP65
Mounting Torque: Max.40N.m
RH: ≤80%
Temp.Measurement: J type TC,K type TC,E type TC,Pt100 RTD

D0	1/2-20UNF	M14×1.5	M18×1.5	M12×1.5
D1	φ8	φ8	φ10	φ8
D2	φ11.5	φ12.5	φ16.5	φ10.4
D3	φ13.5	φ14.5	φ20	φ12.5
L1	5.8	5.8	5.8	5.8
L2	10	10	11	10
L3	19	19	25	19

D0	M22×1.5	M20×1.5	G3/4	G3/8
D1	φ16.2	φ14	φ18	φ10
D2	φ20.5	φ18.7	φ24.5	φ15
D3	φ24	φ22	φ28	φ18
L1	10	5.8	5.8	9
L2	5	3	11	4
L3	40	35	25	25
