High temperature melt pressure gauge series

High temperature melt pressure gauge series



High temperature melt pressure gauge series is designed to measure pressure at high temperature in the industries of injection molding and chemical fiber,special diaphragm and highly anti-abrasive coating of which enable it to work normally at high temperature of 400℃. It adopts standard threaded connection and is characterized by high stability and long service life





Feature:
Pressure range:0～100bar or 0～1000bar;
Accuracy level:±1.6%F.S;
Standard signal output: 4～20mA available.
Process connection:1/2-20UNF
Diaphragm Temp: 400℃
E-connection:5-pin standard
Diaphragm material:15-5PH
Protection level:IP65

Application:
Chemical fiber industry,rubber industry and plastic extrusion industry.
